DirectLOGIC 06 Programmable Logic Controllers (DL06 PLCs)
DL06 PLC Units
The DL06 micro PLC line has nine base units to choose from, each has 20 built-in inputs and 16 built-in outputs.
The DL06 is a great fit for high voltage, 220-240 VAC applications or remote 12 VDC applications, and everything in between.
The DL06 line of modular micro PLCs offers an inexpensive solution for small to medium size I/O applications with features such as:
- 20 built-in inputs and 16 built-in outputs, expandable to 100 I/O total
- Nine combinations of AC or DC powered PLC units with AC, DC and relay I/O
- 14.8 KB of total memory
- 229 instructions, including 8 PID loops
- Built-in real-time clock/calendar
- Two communication ports, including RS232/ 422/ 485 capability
- Supports networking for MODBUS RTU, Ethernet, DeviceNET, Profibus, and ASCII in/out
- Integrated high-speed inputs and pulse output
- 12 discrete I/O option modules
- 7 analog I/O option modules
- 7 communications and specialty option modules
- Thermocouple and RTD temperature inputs
- Removable terminal blocks
- ZIPLink compatibility with 16-point discrete I/O option cards
- Optional LCD display for operator interface or maintenance troubleshooting
NOTE: For pricing and to order, click on the VIEW e-store icon.
| I/O and Input Voltage Combinations |
 |
| AC Power, DC Power and General Specifications |
|
| D0-06LCD Snap-in LCD Display (DL06 only) |
|
|
DL06 LCD Display
$75.00
(D0-06LCD)
|
Optional snap-in LCD display (D0-06LCD) for the DL06.
No need to have a laptop to get a critical piece of information in a memory register or a PLC fault message from the DL06.
Program user-defined messages in ladder logic for display on the DL06 LCD message unit to show important values, events, alarms
or faults. Use the LCD display as a diagnostic tool to quickly pinpoint problems..
- Two-line x 16-character display simply snaps into the face of the DL06. No cable or special mounting required!
- ESC, MENU and ENT keys, along with four arrow keys allow for easy and intuitive navigation
- Password protection capabilities available for system parameters like date and time
- Backlight can be turned off for bright locations
|
|
