AcuAMP Ground Fault Sensors

GFS Series AC Ground Fault Sensors

• Good design practice and code require that all AC power systems be grounded. GFS series ground fault sensors are designed to work on grounded AC power systems.


• This sensor monitors all current carrying conductors in grounded single and three-phase delta or wye systems.


• GFS series ground fault sensors offer jumper-selectable setpoints of 5, 10 or 30 mA. This series is available in fixed-core models only.

GFS Series AC Ground Fault Sensors start at $136.00 (GFS30-D1C-24-F)

• Wide Range of Options:
• Mechanical relay outputs with Auto or Manual reset
• Use up to 14 AWG copper wires
• Noise Immunity option for use in EMI/RFI sensitive environments


• Setpoint Options:
• Field selectable 5mA, 10mA or 30mA setpoints makes user adjustments fast, sure and convenient


• Compatible with Standard Equipment:
• Applicable on single- and three-phase systems
• Ideal for use with shunt trip breakers
• Magnetically isolated from monitored circuit and control power
• Built-in feet with optional 35 mm DIN rail adapter available


• Five-year warranty



• UL 1053 recognized, CE certified

GFS Series AC Ground Fault Sensors Overview

• Personnel Protection (typically 5mA)
• Detects sensitive ground fault conditions, which may be injurious to personnel and processes
• Functions as sensor and alarm trigger when part of an overall ground fault protection system


• Equipment Protection (typically 10mA or 30mA)
• For applications where personal protection is not the primary concern
• Higher setpoint capability helps eliminate nuisance tripping while still providing adequate ground fault detection to protect machine electronics


• Regulatory
• Meets requirements as stipulated by governmental and industrial regulatory groups for ground fault sensing

AC Ground Fault Sensors
