Pneumatic Pressure Switches

MPS25 Series Mechanical
Pressure Switches

The ProSense MPS25 series mechanical pressure switches are designed for the toughest applications where conventional pressure switch designs often don't measure up. These cost effective switches, depending on the pressure range, have either an all welded 316 stainless steel sealed diaphragm actuator design or a direct acting 316 stainless steel piston design with a Buna-N O-ring.

• The rugged 316 stainless steel housing provides uncompromising protection and long life in difficult environments. The robust design is resistant to vibration and shock, and provides reliable operation over a wide operating temperature range.
• Pressure ranges from vacuum to 7500 psig are available along with a 1/4 inch NPT male threaded process connection and a precision snap-acting SPDT, 3 Amp, mechanically operated switch output.
• Choose from either an integral 6-foot (1.5m) cable with 1/2 inch NPT male conduit connection, or a DIN 175301-803C L-connector.

Features

• Compact size
• 316 stainless steel housing
• All stainless welded diaphragm or stainless piston and Buna-N O-ring
• Tamper resistant field adjustment
• 1/4 inch NPT male process connection
• Wide operating temperature range
• Precision snap-acting SPDT, 3 Amp mechanically operated switch
• UL*, CSA, CE and RoHS compliant
  (* UL only applies to the MPS25 series units with integral cable)
• 3-year warranty

Applications

• Process control & automation, pumps & compressors, hydraulic systems, pneumatic systems, engine monitoring, presses, machine tools
