Process Control & Measurement > Digital Panel Meters

Digital Panel Meters

ProSense digital panel meters feature IP65-rated faces, pushbutton configuration, and accept a wide variety of process inputs. Display options include analog process signals, load cell, potentiometer inputs, and temperature in either Fahrenheit or Celsius. Available outputs include alarm relays, analog signal re-transmission, and sensor excitation voltage.

1/32 DIN Size

1/8 DIN Size

Digital Panel Meters

ProSense® Panel Meters - outstanding features and performance at a great price

1/32 DIN and 1/8 DIN sizes

ProSense digital panel meters in 1/32 and 1/8 DIN sizes feature IP65-rated meter faces, simple menu-driven pushbutton configuration, and accept a wide variety of input signals.

Available output options include alarm relays, analog signal re-transmission, and sensor excitation voltage.
Process display options include analog process signals, load cell, or potentiometer inputs, and temperature inputs in either °F or °C from RTDs or thermocouples. Inputs from electrical parameters such as AC or DC voltage and amperage are also available. All panels offer selectable decimal point location.
1/32 DIN DPM1 Series panel meters have three panels versions available with a 4-digit (-1999 to 9999) red LED display.
1/8 DIN DPM2 series panel meters feature a 4-digit (-9999 to 9999 and -1999 to 9999) red LED display.
1/8 DIN DPM3 series digital panel meters have a 5-digit (-19999 to 39999) tri-color (red, green, amber) LED display.

Digital panel meters have a 3-year warranty and start at $70.00

ProSense® Digital Panel Meters

DPM1 Series 1/32 DIN

Digital Panel Meters
- DPM1 Series 1/32 DIN

The ProSense DPM1 process meter series offers a simple, low-cost digital display of analog process signals or AC/DC electrical parameters. The 4-digit red LED panel indicator display is easily scaled into any engineering units from -1999 to 9999. DPM1 series meters are loop powered or powered from an external AC or DC power supply. The 1/32 DIN housing takes up minimal panel space and the meter face has an IP65 rating.

(4) types available
48 x 24mm 1/32 DIN
Simple menu-driven pushbutton configuration
4-digit (-1999 to 9999) red LED display
Selectable decimal point location
(temperature input versions have 0.1 or 1 degree resolution)
Input types available:
4-20mA, +/-20mA, +/-100mV, +/-10V, +/-20V, +/-200V,
RTD Pt100 (3-wire), thermocouple Type J, K, T or N
AC/DC voltage input (100/600V) ... New!
AC/DC amperage input (1A/5A) ... New!
Input power options:
loop powered, 21-53VAC (50/60 Hz), 85-265VAC (50/60 Hz), 10.5-70VDC, 100-300VDC
Output options: none, relay, 0/4-20 mA, relay + 0/4-20 mA
Configuration for direct or reverse acting linear processes
3-year warranty

DPM1 Series 1/32 DIN panel meters
start at $70.00

DPM1-A-LP Series (analog in, loop powered)
Panel Meter Overview

DPM1-A-x Series (analog in)
Panel Meter Overview

DPM1-T-x Series (temperature in)
Panel Meter Overview

DPM1-A-(A)2R-x Series (analog in, relay / mA out) Panel Meter Overview

DPM1-E-x Series (AC/DC voltage/amperage) Panel Meter Overview

DPM2 Series 1/8 DIN

DPM2 Series 1/8 DIN
Large Display

Digital Panel Meters
- DPM2 Series 1/8 DIN

The ProSense DPM2 process meter series offers a simple, low-cost digital display of analog process signals, temperature in either Fahrenheit or Celsius from RTD or thermocouple temperature sensors, potentiometer inputs, or AC/DC voltage and amperage electrical parameters. The 4-digit 14mm and 20mm character height red LED process indicator displays are easily scaled into any engineering units from -9999 to 9999 with a selectable decimal point location.

96 x 48mm 1/8 DIN
Simple menu-driven pushbutton configuration
4-digit 14mm (-9999 to 9999) red LED display
4-digit 20mm (-1999 to 9999) red LED display ... New!
Selectable decimal point
Process (+/-10V, +/-200V and +/-20mA)
Temperature (RTD: Pt100, Pt1000, thermocouple: J, K, T, N, Resolution: 1°F, 0.1°F, 1°C, 0.1°C)
Potentiometer (100 Ohm to 100k Ohm)
Resistance (999.9 Ohm, 9999 Ohm and 50k Ohm)
AC/DC voltage input (20/200/600V) ... New!
AC/DC amperage input (1A/5A/shunt 60mV/shunt 100mv) ... New!
AC or DC powered
3-year warranty

DPM2 Series 1/8 DIN panel meters
start at $107.00 (DPM2-AT-HL)

DPM2 Series 1/8 DIN Panel Meters Overview

DPM2E Series (A/C voltage/curent display) Overview

DPM3 Series 1/8 DIN

Digital Panel Meters
- DPM3 Series 1/8 DIN

The ProSense DPM3 process meter series offers a simple, feature packed digital display of analog process signals, temperature in either Fahrenheit or Celsius from RTD or thermocouple temperature sensors, load cell, potentiometer inputs, or True RMS AC or DC voltage and amperage electrical parameters. The 5-digit tri-color red / green / amber LED process indicator display is easily scaled into any engineering units from -19999 to 39999 with a selectable decimal point location.

96 x 48mm 1/8 DIN
Simple menu-driven pushbutton configuration
5-digit (-19999 to 39999) tri-color (red, green, amber) LED display
Selectable decimal point
Process (+/-10V, +/-20mA)
Temperature (RTD: Pt100; thermocouple: J, K, T, N, Resolution: 1°F, 0.1°F, 1°C, 0.1°C)
Potentiometer
Load cell (+/-15mV, +/-30mV, +/-150mV)
New! ... True RMS AC or DC voltage input (2/20/600V)
New! ... True RMS AC or DC amperage input (200mA/1A/5A/shunt 50mV/shunt 100mv)
AC or DC powered
Sensor excitation voltage 24V and 10V
Display scaling or process teaching modes
4-20mA analog output on select models
3-year warranty
